South Africa’s Ride Farr Introduces Two Frame Models: GMX and ATB

Radar

South Africa’s Ride Farr Introduces Two Frame Models: GMX and ATB

Ride Farr announced today two new framesets in their catalog. Known for their aero bars and other ultra-endurance accessories, these frames are a milestone for the brand. The Gravel Monster (GMX) aluminum frame ($695) and All Terrain Bicycle (ATB) steel ($495) frames were designed from the ground up, with bikepacking, and long rides in mind. The GMX features its own 483mm Axle-to-Crown steel rigid fork that is suspension corrected for 100mm 29er travel, while the ATB rolls on a steel chassis and 120/130mm travel. Head to Ride Farr to see all the details.

Cinelli’s King Zydeco Frameset Clears a 2.1″ Tire and Features a Dual Rake Fork

Radar

Cinelli’s King Zydeco Frameset Clears a 2.1″ Tire and Features a Dual Rake Fork

Over the years, Cinelli has addressed trends within the cycling industry and their latest is the King Zydeco frameset, an update to the original Zydeco which was launched a decade ago. A lot has changed in ten years. Back then ‘cross bikes were “gravel” bikes and disc brakes on drop bar bikes were still working out all the kinks.

The King Zydeco has tire clearance on-par with other offerings in the field. The frameset’s double dropped chainstays allow for a 700 x 40mm or 27.5 x 2.1″ tire.

There’s also a double rake feature, thanks to the Columbus Futura fork and with a claimed frame+fork weight coming in around 1550 grams, the Zydeco is designed to be a race-ready machine. With all these features, you can build this up to suit your specific needs. The above photo of the complete bike is only for reference. ;-) Check out more at Cinelli’s USA website.

Features:
-Headset: IS 42 / 28.6 | IS 52/40
-Seat Post: 27.2mm
-Seat Clamp: 31,8mm
-BB Shell: BB386EVO 86.5mm
-F/Derailleur: Clamp 31,8mm
-Cable Routing: Internal – Di2/EPS Compatible
-Tire Clearance: up to 700x42C / 27.5×2.1 Inches
-Fork: COLUMBUS Futura CROSS 1-1/8″ – 1-1/2″ Tapered Carbon Monocoque
-Weight: Frame 1000g (size M) – Fork 550g
-Brake: Flat mount disc brake, rotor size up to 160mm
-Dropouts St: Rear TA 12x142mm, Front TA 12x100mm
-Frame Kit: Extra Hanger / Di2/EPS cable inserts / Front & Rear skewer

A First Look at the Condor x PEdAL ED Bivio Odyssey All Road Frameset

Radar

A First Look at the Condor x PEdAL ED Bivio Odyssey All Road Frameset

Photos by @saltlake_lian

At the UK handbuilt bicycle show in Bristol, this weekend Condor Cycles showed off their new, made in Italy Bivio Odyssey frameset. It is a collab with the Italian clothing brand, PEdALED.

Condor teamed up with PEdALED in 2017 and 2018 with their pro cycling team but at the 11th hour, just before the start of the 2018 Tour of Britain, their key sponsor JLT, gave Condor some bad news they wouldn’t be continuing as they had been taken over unexpectedly, leaving them with a bit of a void. Condor really enjoyed teaming up with PEdAL ED as they are a very relaxed and easy to work with brand, so they decided to make an aluminum frame inspired by the Silk Road Mountain Race they sponsor and newly-launched Odyssey clothing range.

The Ritchey Ultra MTB Frame

Radar

The Ritchey Ultra MTB Frame

As a throwback to the original Ultra 30 years ago, Ritchey has re-released this 120mm suspension hardtail, with a modern geometry, clearances for either a 27.5”x2.8” or 29”x2.4” tires, and a sleek Sierra grey color. Head to Ritchey for the full geometry specs and your local dealer to check one out.

The Demon Frameworks KS200 Track Frameset

Radar

The Demon Frameworks KS200 Track Frameset


Photos and words by Tom Warmerdam

I saw a Rossin Olympic for the first time in 2016 and was instantly in love. This was a whole new bicycle shaped canvas to play with and I was eager to see what I could come up with. I’d already been exploring lines and slots on my other frames but this new canvas could take that to a whole new level.

I wanted my version to be visually brutal but elegant. So after designing many variations of the webbed plates I sat down and selected my favorite. Then it was time to start. I do all my own work, I don’t outsource anything. So I programmed my old CNC machine and made the plates first. Then the dropouts. I then made a frame to fit and put it all together. I didn’t like how the old Rossin was put together… lots of filler, that’s just not my style. So I brazed in the plates with silver to reduce the chance of heat distortion on the thin-walled tubes. This is a lot more work but also much more satisfying.

But then there was a long pause… partly because I had to focus on my customer’s frames but also because I wanted to use my own fork design based on Max ( I actually based it on Reynolds Speed Stream fork blades as they don’t change shape when you cut them to length) style aero blades. My friend Anna Schwinn had already helped me to translate my 2D drawings and sketches of a fork crown into a usable 3D model (I could not have done this part without her, she was awesome). Then it was a long wait for the molds and castings to be made. They arrived last month so it was time to finally finish it.

Check out more photos of this unique frame below and follow Demon Frameworks on Instagram!

Crust Bikes: Lightning Bolt Randonneuring Frameset

Radar

Crust Bikes: Lightning Bolt Randonneuring Frameset

Writing product description takes finesse, yet clearly, Matt from Crust Bikes really enjoyed writing about their newest frameset, the Lightning Bolt:

“The Lightning bolt is a dedicated low trail randonneur frame. Unlike the rest of our frames this one is designed with pavement in mind. Max tire clearance is 650b X 48c. Compatible with both 1X, 2X or even triple chainring set up. Main tubes are made from some pretty thin wall Renoylds 853, which I noticed a bunch of people wanted the Romanceur to be, so here it is. Will it plane I hear you ask? It flexes in such a harmonic resonance, you will think you are surfing Kelly slaters wave pool riding a Mick Mackie flex tail fish, doing the smoothest high lines this side of Derek Hynd at J.Bay, it just planes that good! What am I talking about I hear you ask? Contact Jan Heine to find out, be sure to mention Kelly Slaters wave pool, I mean come on people! How is no one else trying to make a bike ride like a surfboard on an artificial wave?”

See more at Crust Bikes!

Own a True Temper Slim Chance Road Frame

Radar

Own a True Temper Slim Chance Road Frame

If you’re looking for a new steel road frameset, check out the latest offering from Fat Chance. These True Temper Slim Chance frames come with a number of configuration options. You can choose a steel fork, or an ENVE, color-matched ENVE stem, and even a color-matched Silca frame pump. You can even select if you want a cabled road groupset or SRAM Red eTap. The pricing starts at $2395 for a frame, fork and King headset, allowing you to tack on options as needed. This pre-order is a limited edition offering, and will close out on November 15th with a end of January 2017 delivery.

Head to Fat Chance for the skinny on the new Slim Chance.

OD OG1

Radar

OD OG1


Photo by Kyle Kelley

Since reviewing the Speedvagen OG1, I really wanted to own one, but as a frame. As of now, if you recall, the OG1 only comes as a complete. Yet after a few emails, I was able to finagle one out of the Vanilla Workshop and two weeks later, it arrived. Not sure if this will be something Vanilla offers in the future, yet their comment on Instagram leads me to believe it might be an option in 2017. Or you could holler at them and beg like I did.

The guys at Golden Saddle will be building this up in the next week, with SRAM Rival and some Chris King special bits…

VYNL Bikes Launch a ‘Cross Frameset

Radar

VYNL Bikes Launch a ‘Cross Frameset

VYNL made a splash with its made in the USA aluminum road bikes last year and now, they’re ready for dirt. These new CX frames are made by Frank the Welder from 7005 butted aluminum, feature a threaded BB, 135mm rear spacing, thru axles, 44mm head tube, and fit 40mm tires. You also have an option to include a ENVE Disc CX Fork, and can chose from six colors. For more information and to put down a deposit, head to VYNL. If you’re a local dealer, leave your information in the comments.

Parra for Colossi

Radar

Parra for Colossi

Dutch artist, Piet Parra has teamed up with Sander and Jan from Colossi to paint a limited run of classic Columbus SL tubed road frames. These frames are available only as a custom geometry and are priced for a price of $1,365. Head over to Parra’s site for more photos and information.

The Return of the Slim Chance

Radar

The Return of the Slim Chance

While Chris Chance and Fat City might be known best for their MTB, segmented forks and revolutionizing the tig-welding process for frame building, they also had a very successful road bike, dubbed the Slim Chance 2.0. Well, with the relaunch of the brand and its hardtail MTBs, Fat City has just announces their new Slim Chance frames… Check out these details and head over to Fat Chance to see more!

-Available as a frame, ENVE carbon fork and Chris King headset package for $2295.
-Segmented steel Yo Road Fork will be available as an option in the coming weeks.
-Painted stem upgrade options; Carbon (ENVE) for $355, Alloy for $250.
-Choice of mechanical or electronic shifting options at no extra charge.
-4 colors inspired some of our favorite Slim’s from the past; Blue, Pearl White, Pale Yellow and Red.
-Framesets ship in 4-6 weeks, complete bikes in 6-8 weeks.
